The Coti Global CG-SSB-10 is an alloy steel single-ended beam (shear beam) load cell. Stainless steel single ended beam load cell utilized in small tanks, hoppers and silos. 1000 ohm. 40K capacity.
Interchangeable with: HBM SB4.
This listing is the 40K model, Coti Global part CG-SSB-10 40K. This capacity is not NTEP approved.
Coti Global CG-SSB-10 40K Alloy Steel Single Ended Beam Load Cell
SKU: CG-SSB-10 40K
$2,400.00 Regular Price
$2,232.00Sale Price
| Model | CG-SSB-10 |
| Material | Alloy Steel |
| Type | Single-ended beam (shear beam) load cell |
| Rated Capacity | 40K |
| Capacities In This Line | 40K |
| NTEP | Not NTEP approved |
| Interchangeable With | HBM SB4 |
| Rated Output | 2.00 mV/V ±0.25% |
| Safe Overload | 150% FS |
| Excitation Voltage | 10V AC/DC (15V max) |
| Input Resistance | 1080 ±10 Ω |
| Output Resistance | 1000 ±5 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally Sealed, IP67 |
| Non-Linearity | ±0.03% FS |
| Hysteresis | ±0.03% FS |
| Repeatability | ±0.01% FS |
| Creep | ±0.02% FS in 30 minutes |
| Compensated Temperature Range | -10°C to +40°C |
| Temperature Effect on Zero | ±0.0027% FS/°C |
| Temperature Effect on Output | ±0.0015% FS/°C |
| Insulation Resistance | 5,000 MΩ |
| Load Cell Cable | 4 conductor 22 AWG, Ø6.8mm, braided shield, 50 ft |
| Load Cell Wiring | Green +EXC, Black -EXC, White +SIG, Red -SIG, Braid/Yellow Shield |
| Approvals | FM Approved |
