The Coti Global CGSB is a alloy steel S-beam (S-type) load cell for tension and compression applications, commonly used in suspended hopper and tank weighing. Available in capacities from 25 lb to 40K. This capacity is not ntep approved.
Interchangeable with: Celtron STC, Rice Lake RL20001, Sensortronics 60001.
This listing is the 40K model, Coti Global part CGSB 40K.
Coti Global CGSB 40K Alloy Steel S-Beam Load Cell
SKU: CGSB 40K
$1,210.00 Regular Price
$1,125.30Sale Price
| Model | CGSB |
| Material | Alloy Steel |
| Type | S-beam (S-type) load cell, tension/compression |
| Rated Capacity | 40K |
| Capacities In This Line | 25 lb to 40K |
| NTEP | Not NTEP approved |
| Interchangeable With | Celtron STC, Rice Lake RL20001, Sensortronics 60001 |
| Rated Output | 3.00 mV/V ±0.25% |
| Safe Overload | 150% FS |
| Excitation Voltage | 10V AC/DC (15V max) |
| Input Resistance | 385 ±10 Ω |
| Output Resistance | 350 ±3 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally Sealed, IP67 |
| Non-Linearity | ±0.03% FS |
| Hysteresis | ±0.02% FS |
| Repeatability | ±0.01% FS |
| Creep | ±0.02% FS in 30 minutes |
| NTEP Class | Class IIIL, 10,000 divisions, single cell |
| Compensated Temperature Range | -10°C to +40°C |
| Temperature Effect on Zero | ±0.0027% FS/°C |
| Temperature Effect on Output | ±0.0015% FS/°C |
| Insulation Resistance | 2000 MΩ |
| Load Cell Cable | 4-26 AWG, Ø3.8 mm, PVC, 20 ft (25-200 lb); 4-24 AWG, Ø5.6 mm, PVC, 20 ft (250 lb-40K) |
| Load Cell Wiring | Green +EXC, Black -EXC, White +SIG, Red -SIG, Braid/Yellow Shield |
| Approvals | NTEP, FM Approved |
Documentation:
