The Coti Global CG-23-1 is an alloy steel single-ended beam (shear beam) load cell. Coti Global's alloy steel single ended beam load cells feature a common shear beam, through hole & NTEP capacities between 250lb-20K.
Interchangeable with: Artech 30210, Rice Lake RL30002, Tedea 3410.
This listing is the 100 lb model, Coti Global part CG-23-1 100 lb. This capacity is not NTEP approved.
Coti Global CG-23-1 100 lb Alloy Steel Single Ended Beam Load Cell
SKU: CG-23-1 100 lb
$210.00 Regular Price
$195.30Sale Price
| Model | CG-23-1 |
| Material | Alloy Steel |
| Type | Single-ended beam (shear beam) load cell |
| Rated Capacity | 100 lb |
| Capacities In This Line | 100 lb to 20K |
| NTEP | Not NTEP approved |
| Interchangeable With | Artech 30210, Rice Lake RL30002, Tedea 3410 |
| Rated Output | 3.00 mV/V ±0.25% |
| Safe Overload | 150% FS |
| Excitation Voltage | 10V AC/DC (15V max) |
| Input Resistance | 385 ±10 Ω |
| Output Resistance | 350 ±3 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally Sealed, IP67 |
| Non-Linearity | ±0.03% FS |
| Hysteresis | ±0.02% FS |
| Repeatability | ±0.01% FS |
| Creep | ±0.02% FS in 30 minutes |
| Compensated Temperature Range | -10°C to +40°C |
| Temperature Effect on Zero | ±0.0027% FS/°C |
| Temperature Effect on Output | ±0.0015% FS/°C |
| Insulation Resistance | 5,000 MΩ |
| Load Cell Cable | 4 conductor 24 AWG, Ø5.6mm, PVC, 20 ft |
| Load Cell Wiring | Green +EXC, Black -EXC, White +SIG, Red -SIG, Braid/Yellow Shield |
| Approvals | FM Approved |
Documentation:
