The Coti Global CG-23 is a alloy steel single ended beam load cell for industrial weighing. Single ended beam (shear beam) load cells are used in platform scales, belt scales, tank and hopper weighing, and industrial process weighing. Available in capacities from 100 lb to 20K. This capacity is not ntep approved.
Interchangeable with: Artech 30310, Celtron SQB, HBM A35*, Revere 5123, Rice Lake RL30000, Rice Lake RL35023*, Sensortronics 65023*, Tedea 3411, Totalcomp TSB, Transcell SBS, Zemic H8C.
This listing is the 100 lb model, Coti Global part CG-23 100 lb.
Coti Global CG-23 100 lb Alloy Steel Single Ended Beam Load Cell
SKU: CG-23 100 lb
$210.00 Regular Price
$195.30Sale Price
| Model | CG-23 |
| Material | Alloy Steel |
| Type | Single ended beam (shear beam) load cell |
| Rated Capacity | 100 lb |
| Capacities In This Line | 100 lb to 20K |
| NTEP | Not NTEP approved |
| Interchangeable With | Artech 30310, Celtron SQB, HBM A35*, Revere 5123, Rice Lake RL30000, Rice Lake RL35023*, Sensortronics 65023*, Tedea 3411, Totalcomp TSB, Transcell SBS, Zemic H8C |
| Rated Output | 3.00 mV/V ±0.25% |
| Excitation Voltage | 10 V AC/DC (15 V max) |
| Input Resistance | 385 ±10 Ω |
| Output Resistance | 350 ±3 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally sealed, IP67 |
| Safe Overload | 150% FS |
| Non-Linearity | ±0.03% FS |
| Hysteresis | ±0.02% FS |
| Repeatability | ±0.01% FS |
| Creep | ±0.02% FS in 30 minutes |
| NTEP | Class IIIL, 10,000 division, multiple cell (NTEP capacities only) |
| Compensated Temperature Range | -10°C to +40°C |
| Temperature Effect on Zero | ±0.0027% FS/°C |
| Temperature Effect on Output | ±0.0015% FS/°C |
| Insulation Resistance | 5,000 MΩ |
| Cable | 4-conductor 24 AWG, Ø5.6 mm, PVC, 20 ft |
| Wiring | Green (+Excitation), Black (-Excitation), White (+Signal), Red (-Signal), Braid/Yellow (Shield) |
| Approvals | FM |
Documentation:
