The Coti Global CG-PWS is a stainless steel single point load cell, available in capacities from 7 kg to 150 kg. This capacity is not ntep approved.
Interchangeable with: HBM PWS, Rice Lake RL1380.
This listing is the 7 kg model, Coti Global part CG-PWS 7 kg.
Coti Global CG-PWS 7 kg Stainless Steel Single Point Load Cell
SKU: CG-PWS 7 kg
$340.00 Regular Price
$316.20Sale Price
| Model | CG-PWS |
| Material | Stainless Steel |
| Type | Single point load cell |
| Rated Capacity | 7 kg |
| Capacities In This Line | 7 kg to 150 kg |
| NTEP | Not NTEP approved |
| Interchangeable With | HBM PWS, Rice Lake RL1380 |
| Rated Output | 2.00 mV/V ±10% |
| Safe Overload | 150% FS |
| Excitation Voltage | 10-20V AC/DC |
| Input Resistance | 385 ±10 Ω |
| Output Resistance | 350 ±3 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally Sealed, Potted IP67 |
| Non-Linearity | ±0.03% FS |
| Hysteresis | ±0.02% FS |
| Repeatability | ±0.02% FS |
| Creep | ±0.03% FS |
| Compensated Temperature Range | -10°C to +40°C |
| Temperature Effect on Zero | ±0.02% FS/°C |
| Temperature Effect on Output | ±0.001% FS/°C |
| Insulation Resistance | >5,000 MΩ |
| Load Cell Cable | 4 Conductor, 10 FT |
| Load Cell Wiring | Green +EXC, Black -EXC, White +SIG, Red -SIG, Braid/Yellow Shield |
| Max Platform Size | 400 X 400 mm |
| Approvals | FM Approved |
Documentation:
