The Coti Global CG-SB250 is a stainless steel single-ended beam (shear beam) load cell. Stainless steel single ended beam load cell with insert. Common applications are small tanks, hoppers and platform scales.
Interchangeable with: Cardinal SB10000S, Cardinal SB20000S, Cardinal SB2500S, Cardinal SB5000S, Rice Lake RLSB250.
This listing is the 2.5K model, Coti Global part CG-SB250 2.5K. This capacity is NTEP approved (NTEP: 1:5000, Class III-M).
Coti Global CG-SB250 2.5K Stainless Steel Single Ended Beam Load Cell
SKU: CG-SB250 2.5K
$620.00 Regular Price
$576.60Sale Price
| Model | CG-SB250 |
| Material | Stainless Steel |
| Type | Single-ended beam (shear beam) load cell |
| Rated Capacity | 2.5K |
| Capacities In This Line | 2.5K to 20K |
| NTEP | NTEP: 1:5000, Class III-M |
| Interchangeable With | Cardinal SB10000S, Cardinal SB20000S, Cardinal SB2500S, Cardinal SB5000S, Rice Lake RLSB250 |
| Rated Output | 2.00 mV/V ±0.1% |
| Safe Overload | 150% FS |
| Excitation Voltage | 10-20V AC/DC |
| Input Resistance | 385 ±10 Ω |
| Output Resistance | 350 ±3 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally Sealed, IP67 |
| Non-Linearity | ±0.03% FS |
| Hysteresis | ±0.02% FS |
| Repeatability | ±0.01% FS |
| Creep | ±0.02% FS |
| NTEP Class | Class III, 5,000 divisions, multiple cell |
| Compensated Temperature Range | -10°C to +40°C |
| Temperature Effect on Zero | ±0.0027% FS/°C |
| Temperature Effect on Output | ±0.0015% FS/°C |
| Insulation Resistance | >5,000 MΩ |
| Load Cell Cable | 4 conductor, 30 ft |
| Load Cell Wiring | Green +EXC, Black -EXC, White +SIG, Red -SIG, Braid/Yellow Shield |
| Approvals | FM Approved |
Documentation:
