The Coti Global CG-50 is a aluminum single point load cell, available in capacities from 50 kg to 1000 kg. This capacity is not ntep approved. Features overload stop and potted construction.
Interchangeable with: Anyload 108UAUN, Artech 60410, CAS BCM, Celtron LOC, HBM PW12, Revere 652, Rice Lake RL1250, Rice Lake RLPWM12, Sensortronics 60060, Tedea 1250, Transcell FAY.
This listing is the 635 kg model, Coti Global part CG-50 635 kg.
Coti Global CG-50 635 kg Aluminum Single Point Load Cell
SKU: CG-50 635 kg
$350.00 Regular Price
$325.50Sale Price
| Model | CG-50 |
| Material | Aluminum |
| Type | Single point load cell |
| Rated Capacity | 635 kg |
| Capacities In This Line | 50 kg to 1000 kg |
| NTEP | Not NTEP approved |
| Construction | Overload stop, Potted construction |
| Interchangeable With | Anyload 108UAUN, Artech 60410, CAS BCM, Celtron LOC, HBM PW12, Revere 652, Rice Lake RL1250, Rice Lake RLPWM12, Sensortronics 60060, Tedea 1250, Transcell FAY |
| Rated Output | 2.00 mV/V ±10% |
| Safe Overload | 150% FS |
| Excitation Voltage | 10-20V AC/DC |
| Input Resistance | 410 ±10 Ω |
| Output Resistance | 350 ±3 Ω |
| Zero Balance | ±1.00% FS |
| Seal Type | Environmentally Sealed, Potted, IP67 |
| Non-Linearity | ±0.02% FS |
| Hysteresis | ±0.02% FS |
| Creep | ±0.03% FS |
| Compensated Temperature Range | 0°C to +30°C |
| Temperature Effect on Zero | ±0.002% FS/°C |
| Temperature Effect on Output | ±0.001% FS/°C |
| Insulation Resistance | >5,000 MΩ |
| Load Cell Cable | 4 Conductor, 10 FT |
| Load Cell Wiring | Green +EXC, Black -EXC, White +SIG, Red -SIG, Braid/Yellow Shield |
| Max Platform Size | 50-500kg 600 X 600 mm; 635-1000kg 800 X 800 mm |
| Approvals | FM Approved |
