  • Stainless steel platter
  • ABS injection-molded plastic base
  • Single-point strain gauge load cell
  • Adjustable legs
  • Leveling bubble
  • 14-pin connector on three-meter cable



The DIGI S-YC Platform Series is constructed of durable ABS plastic and stainless steel, making it an ideal choice for industrial and food operations. The S-YC Series is easy to clean and endures tough applications. These platforms contain the highest quality load cells—extremely durable and able to withstand high overloads.

DIGI® S-YC Series Remote Scale Base Platforms

$700.00 Regular Price
$630.00Sale Price
  • Output Impedance:
    350 ±5 ohms

    Insulation Resistance:
    >500 Megohms

    Rated Output:
    1.0016 mV/V

    Color Code:
    Green + Output
    Yellow – Output
    Black Shield
    White – Input
    Red + Input

    Load Cell Type:
    K-Type DIGI cell

    Load Cell Cable Length:
    118 in (3 m)

    Operating Temperature:
    14 °F to 104 °F (-10 °C to 40 °C)

    Warranty:
    Two-year limited
