Is the RL1385 NTEP certified?

The 10 kg through 75 kg models are NTEP certified (00-125) and FM approved. Rice Lake's part data does not list NTEP for the 100 kg and 200 kg models.

Environmentally sealed, IP67. The body is stainless steel.

What cable is included?

3 meters (about 10 ft) of cable.

What capacities are available?

The RL1385 comes in 10, 15, 30, 50, 75, 100 and 200 kg. This listing is the 200 kg model (Rice Lake part 41406).

What warranty does it carry?

The RL1385 is covered by a two-year limited warranty.

The Rice Lake RL1385 is a stainless steel single point load cell, environmentally sealed to IP67. The 10 kg through 75 kg models are NTEP certified (00-125) and FM approved. Built for bench scales and packaging equipment in damp environments.

This listing is the 200 kg model, Rice Lake part 41406.

Rice Lake RL1385 200 kg Stainless Steel Single Point Load Cell

Name: Rice Lake RL1385 200 kg Stainless Steel Single Point Load Cell
Brand: Rice Lake Weighing Systems
SKU: 41406
Price: 443.61 USD
Availability: InStock

SKU: 41406

$477.00

$443.61

Quantity

Full Scale Output	2.0 mV/V
Output Resistance	330 (±25) ohm
Input Resistance	390 (±20) ohm
Material/Finish	Stainless steel
Temperature	Operating: 0 to 150 °F (-18 to 65 °C)
Seal Type	Environmentally sealed, IP67
Safe Overload	200% full scale
Rated Excitation	5 VDC (15 V maximum)
Combined Error	0.02% full scale
Insulation Resistance	5,000 megohm
Cable Length	10 ft
Cable Diameter	0.196 in; Polyurethane jacket
Cable Color Code	Green +Excitation; Black -Excitation; White +Signal; Red -Signal; Yellow shield
Max Platform Size	18 × 18 in
Warranty	Two-year limited
Approvals	NTEP 00-125; FM
